MIL MIL-PRF-19500/753C PDF

Original price was: $40.00.Current price is: $20.00.

TRANSISTOR, FIELD EFFECT RADIATION HARDENED N-CHANNEL, SILICON, ENCAPSULATED (SURFACE MOUNT PACKAGE), TYPES 2N7580, 2N7582, 2N7584, AND 2N7586, JANTXV, AND JANS (SUPERSEDING MIL-PRF-19500/753B)

Published by	Publication Date	Number of Pages
MIL	03/17/2017	24

Category: MIL

Description
Documents History

MIL MIL-PRF-19500/753C – TRANSISTOR, FIELD EFFECT RADIATION HARDENED N-CHANNEL, SILICON, ENCAPSULATED (SURFACE MOUNT PACKAGE), TYPES 2N7580, 2N7582, 2N7584, AND 2N7586, JANTXV, AND JANS (SUPERSEDING MIL-PRF-19500/753B)

MIL-PRF-19500/753C covers the performance requirements for a N-channel, enhancement-mode, MOSFET, radiation hardened (total dose and single event effects (SEE)), power transistor. Two levels of product assurance (JANTXV and JANS) are provided for each encapsulated device with avalanche energy maximum rating (EAS) and maximum avalanche current (IAS). Provisions for radiation hardness assurance (RHA) to three radiation levels (“R”, “F”, and “G”) are provided for JANTXV and JANS product assurance levels.
